Basic Logic Circuit Design

소개

연세대학교 전기전자기초실험 예비 래포트입니다. 누구한테 준 적 없는 자료이구요 ~ A0 받았습니다 ~~

목차

①Explain how to design logic gates with transistors.
②Design XOR gate with 2 input AND, OR, NAND, NOR, NOT gates.
③Describe the followings : TTL(Transistor Transistor Logic),ECL(Emitter Coupled Logic),MOS(Metal Oxide Semiconductor),CMOS(Complementary Metal Oxide Semiconductor)
④Using Karnaugh map, express boolean algebra equation from T/F table.
⑤Build boolean algebra equation of full/half adder.

본문내용

Complementary metal–oxide–semiconductor is a technology for making integrated circuits. CMOS technology is used in microprocessors, microcontrollers, static RAM, and other digital logic circuits. CMOS technology is also used for a wide variety of analog circuits such as image sensors, data converters, and highly integrated transceivers for many types of communication. CMOS is also sometimes referred to as complementary-symmetry metal–oxide–semiconductor. The words complementary-symmetry refer to the fact that the typical digital design style with CMOS uses complementary and symmetrical pairs of p-type and n-type metal oxide semiconductor field effect transistors for logic functions. Two important characteristics of CMOS devices are high noise immunity and low static power consumption. Significant power is only drawn when the transistors in the CMOS device are switching between on and off states.

참고자료

· 없음
